Continuous Flow Settings |
0 - 5 LPM, LPM= Liter Per Minute |
|
Oxygen Concentrations |
93% +/- 3% at 1 LPM 60% +/- 3% at 3 LPM 40% +/- 3% at 5 LPM |
|
Outlet Pressure |
8.5 PSI |
|
Sound Level |
≤ 43 dB (nominal) at any setting |
|
Size |
10.2 in x 7.7 in x 15.2 in(26 cm x 19.5 cm x 38.7 cm) |
|
Weight |
12 lbs (5.4 kg) without battery |
|
User Interface |
Push buttons, back-lit liquid crystal display (LCD) |
|
Filtration |
air inlet filter, bacteria filter |
|
Operational Temperature |
41° to 104°F (5° to 40°C) |
|
Relative Humidity |
15 to 95% |
|
Altitude |
Up to 12,000 ft (3657 m) |
|
AC Power Output |
14.8 VDC, 8 A max |
|
DC Power Input |
Input 11. to 16.8 VDC 20 A max |
|
Audible Alarm Sound Level |
55 dB (nominal) at 39 in (1 m) |
