IN-B3000 ICEN lab Auto Urine Sediment Analyzer Urine Analyzer

Type:
Bacteria Analysis System
Brand Name:
ICEN
Model Number:
IN-B1200
Place of Origin:
Guangdong, China
Instrument classification:
Class I
Warranty:
1 Year, 1 Year
After-sale Service:
Online technical support
Application:
Hosipital
Test p
Description

IN-B3000 ICEN lab Auto Urine Sediment Analyzer Urine Analyzer

Product Description:

Work Principle
Use flow counting cell technology, medical image scanning technology and artificial intelligence identification technique to capture real images of urine formed elements, and then locate, track, recognize, classify and count them.



The most advanced Four channels design
Single sample sucking needle with four-channels counting cell technology, one channel detecting and others subsiding or cleaning, fully guarantee the test speed is 120 samples/hour.



Sample loading system
Fully automatic track type walk away mode: after placing the samples, the instrument automatically keeps conducting samples scanning, locating, mixing, aspiration and detection without centrifugation. The Max. sample loading capacity is 6 racks of 10 tubes.



Auto focusing technology
Automatic focusing technology for microscope without focusing liquid, fully guarantee clarity of the images and reduce maintenance costs.



Washing system
Use high precision PTFE coating sample sucking needle to clean the pipeline more thoroughly, to prevent cross contamination as
much as possible.



Main Technical Specifications:

Test items: RBC, WBC, Epithelial, Casts, Crystals, Bacteria, Yeast, , Mucus,WBCC and other components in urine; RBC morphology analysis (Erythrocyte phase)
Detection principle:Flow cell digital imaging technology, medical image fusion technology, artificial intelligence identification technique.
Channel: Four channels fixed flow counting cell
Detection speed: 120~160 samples/h
Sample volume: Minimum volume: 3 ml
                             Aspirating volume: l ml
Test sensitivity: 5 objectives/ul
Accuracy:>95%
Repeatability: CV <10%
Cross contamination rate: <0.05%
Data storage: 200000
Report model: International general quantitative unit: unit /ul & HPF, complete and illustrated report, with urine chemistry test results and urine formed elements test results
Environment: Temperature 15°C~35°C, Optimum temperature 20°C~25°C, Relative humidity≤75%
Power supply: AC 100-240V 50/60HZ
Dimensions(main unit): 660mm*440mm*570mm(L*W*H)
Weight: 33kg


  • How to buy your products ?Do you have distributor in our country?

    You can buy the products from our company directly.Normally the procedure is:Sign the contact ,payment  byT/T, contact the shipping company to delivery the goods to your country.

  • What is the warranty?

    The free warranty is one year from the day of Commissioning qualified.

  • Can we visit your country ?

    Of course,we will prepare for everything in advance if it is necessary .Generally,it is require that customers must have build agency relationship or business relationship with our company.
  • How long is the validity of quotation?

    Generally,our price is valid within one month from the date of quotation .The price will be adjusted appropriately according to the price fluctuation of raw material and changes in market .
  • Do you have the CE certificate ?

    Yes, most of our products have the CE certificate.
